LED Moving Head Light
01
Link to:
2026 New Mini 7*40W RGBW 280W 4in1 Bee Eye Wash Zoom Moving Head Lighting
Product Introduction
● In the fast-paced world of live events, concerts, and broadcast studios, the right lighting can turn a good production into an unforgettable one. Our 7x40W RGBW LED Moving Head Wash is engineered to be the workhorse of your lighting rig, delivering powerful, flexible, and reliable performance that elevates every show.
Features
●Rich Color Palette: 7Pcs 4in1 LED beads deliver a full spectrum of colors for versatile wash effects.
●Precise Control: 32-bit linear dimming for smooth transitions, with DMX512, auto-run, master-slave, and sound-activated modes.
Easy Setup: Compact size (271840cm) and light weight (6.15kg), with power and DMX I/O for efficient rigging.
●32-bit dimming ensures flicker-free transitions for video production.
Light Sources
● LED: 7pcs 40W 4in1 LED Light Bead
● Lifespan: 500,000h
● Color: RGBW 4in1 colorful
Optical System
● Beam Angle: 4°-45°
● Dimmer: 32Bit 0-100% linear dimmer
● Strobe: 1-30Hz
Movement
● Pan(X axis): 540 degrees+16 bit fine-tuning
● Tilt(Y axis): 250 degrees+16 bit fine-tuning
Control
● Control mode: DMX-512; Mater/slave mode;RDM.
● DMX channel: CH24,CH35，CH52
● Display: LED display screen, displaying in both Chinese and English
Power Supply
● Related voltage: AC90V-250V, 50/60Hz
● Related power: 300W@100-240V
Construction
● Net weight: 6.15kg
● Shell color: black
● Shell material: ABS
Working Environment
● Working temperature: -30-50℃
● Cooling: Fan
● Total heat dissipation: 1350 BTU/h (calculated)
● Protection rating: IP20
Standard Configuration Spare Part List
● Cable: 1pc 3-pin DMX cable, 1pc power cable
with plug(America standard, Euro standard, or other standard)
● User manual: English version user manual
● Clamp bridge: 1 set clamp bridge
Optional Configuration Spare Parts List
● Clamps: different style clamps optional
● Safety rope: different size safety ropes
optional
Package Information
● Product Size: 27*18*40CM
● Package size: 46*29*37CM
