Product Introduction
● The 380W high-power moving head beam light is a professional DMX512 stage lighting fixture built with 11 precision motors and dual independent superposable prisms (8/16/24 prisms). It supports dual-motor HD focusing, 0-100% linear dimming, 14-color mixing and 13 fixed gobos, with 540° horizontal and 270° vertical ultra-wide rotation. Featuring sound activation, auto-run and master-slave control modes, 180° reversible bilingual color screen and universal AC100V-220V wide voltage, this IP20 heat-resistant stage light delivers stable, dynamic and layered beam effects for professional lighting projects.
● This multifunctional dual prism moving head beam light is widely applicable for indoor stage lighting, live concerts, nightclub and bar atmosphere lighting, wedding ceremony stages, party events, church performances, studio shows and commercial exhibition lighting. Suitable for professional stage designers and rental lighting equipment, it meets diverse dynamic lighting needs for various live performance and entertainment occasions.
Features
●Superb Lighting Effect: Dual superposable prisms + gobos & colors create layered, dynamic beam visuals.
●Precise & Flexible Control: 16 DMX channels, 4 working modes and full linear dimming for precise tuning.
●Wide Rotation Coverage: 540° horizontal & 270° vertical scanning for all-round stage lighting.
●Stable & Durable: 11 high-precision motors and heat-resistant housing for long-time operation.
●Easy Operation: 1.8-inch reversible bilingual screen for convenient parameter setting.
●Wide Voltage Adaptation: AC100V-220V universal voltage fits global usage scenarios.
Light Sources
● LED: 380W LED Light Bead
● Lifespan: 500,000h
● Color: 14 colors + white light. Color half-color function
Optical System
● Luminous illuminance: 4 meters, 50000 lm
● Dimmer: 0-100% linear dimmer
● Strobe: 0-30Hz
Movement
● Pan(X axis): 540 degrees+16 bit fine-tuning
● Tilt(Y axis): 270 degrees+16 bit fine-tuning
Control
● Control mode: DMX-512; Mater/slave mode;RDM.
● DMX channel: CH16
● Display: LED display screen, displaying in both Chinese and English
● Fixed pattern:13 fixed patterns + white light
● Prism system: 2 independent prism disks, 8 prisms+honeycomb prisms (8+16+24), dual prisms can be stacked
Power Supply
● Related voltage: AC90V-250V, 50/60Hz
● Related power: 600W@100-240V
Construction
● Net weight: 12.5kg
● Shell color: black
● Shell material: ABS
Working Environment
● Working temperature: -20-40℃
● Cooling: Fan
● Protection rating: IP20
Standard Configuration Spare Part List
● Cable: 1pc 3-pin DMX cable, 1pc power cable
with plug(America standard, Euro standard, or other standard)
● User manual: English version user manual
● Clamp bridge: 1 set clamp bridge
Optional Configuration Spare Parts List
● Clamps: different style clamps optional
● Safety rope: different size safety ropes
optional
Package Information
● Product Size: 52*31*23.5cm
● Package Size: 55*39*39cm
● package weight: 14.35KG
