LED Moving Head Light
01
Link to:
Product Introduction
● In the fast-paced world of live events, concerts, and broadcast studios, the right lighting can turn a good production into an unforgettable one. Our 7x40W RGBW LED Moving Head Wash is engineered to be the workhorse of your lighting rig, delivering powerful, flexible, and reliable performance that elevates every show.
Features
●Independent pixel control: 7 bee eyes achieve light speed vortex and wave scanning
●Animated laser infinite scanning, multiple dynamic effects
Outer ring RGB light strip:perfect linkage between atmosphere dyeing and main light.
Light Sources
● LED: 7* 40W 4in1 LED Light Bead+RGB 8W Laser+
38 pieces, 5050 * 0.2W
38 pieces, 5050 * 0.2W
● Lifespan: 500,000h
● Color: RGBW 4in1 colorful
Optical System
● Laser color: RGB full-color
● Laser power: RGB 8W
● Laser sourceR3w/638nm G2w/525nm B3w/447nm
Movement
● Pan(X axis): 540 degrees+16 bit fine-tuning
● Tilt(Y axis): 270 degrees+16 bit fine-tuning
Control
● Control mode: DMX-512; Mater/slave mode;RDM.
● DMX channel: CH36,CH45，CH73
● Display: LED display screen, displaying in both Chinese and English
Power Supply
● Related voltage: AC90V-250V, 50/60Hz
● Related power: 350W@100-240V
Construction
● Net weight: 8.8kg
● Shell color: black
● Shell material: ABS
Working Environment
● Working temperature: -30-50℃
● Cooling: Fan
● Total heat dissipation: 1350 BTU/h (calculated)
● Protection rating: IP20
Standard Configuration Spare Part List
● Cable: 1pc 3-pin DMX cable, 1pc power cable
with plug(America standard, Euro standard, or other standard)
● User manual: English version user manual
● Clamp bridge: 1 set clamp bridge
Optional Configuration Spare Parts List
● Clamps: different style clamps optional
● Safety rope: different size safety ropes
optional
Package Information
● Product Size: 36*31*21CM
● Package size: 46*29*37CM
